Description
Multiple telescopic loading stations with synchronous belt drive enable continuous operation. The unloading unit incorporates a movable receiving table with two-stage ejection, maintaining clear workspace separation and facilitating ergonomic material handling.
Parameter
| Parameter | Specification |
| Model | ZDC-180 |
| Machine Weight | ≈140 kg |
| External Dimensions | 665 × 690 × 750 mm |
| Z/Y Axis Travel | 140 × 218 mm |
| Cutting Method | Vertical Cutting |
| Max. Sample Weight | 10 kg |
| Max. Cutting Speed | 0.1 – 100 mm/min |
| Max. Cutting Dimension | Ø180 mm |
| Max. Cutting Thickness | 100 mm |
| Surface Roughness (Ra) | ≤0.2 mm |
| Cutting Accuracy | ±0.05 mm |
| Repeat Positioning Accuracy | ±0.01 mm |
| Wire Tensioning Method | Spring-loaded |
| Diamond Wire Diameter | 0.35 – 0.65 mm |
| Screw & Guide | Precision ground ball screw + Linear guides |
| Wire Guide Bearings | Imported |
| Drive Method | Stepper motor |
| Wire Drive | Servo motor |
| Wire Break Protection | Yes |
| Total Power | 1.3 kW |
| Rated Voltage | AC220V 50-60Hz |
| Power Failure Protection | Yes |
